Keyence VK-X3100 3D Surface Profiler
The Keyence VK-X3100 employs advanced optical white-light technology for non-contact 3D surface profiling with nanometer-level resolution. Equipped with manual XY stages, it measures surface profiles, roughness, and film thickness on a wide range of materials and shapes with exceptional accuracy. This profiler is perfect for detailed surface characterization where contactless measurement is essential.
Sonoscan C-SAM D9000 Scanning Acoustic Microscope
The Sonoscan D9000 uses high-resolution acoustic imaging to inspect interfaces between dissimilar materials, detecting internal defects such as air voids between silicon chips and underfill. Samples are submerged in water to enhance acoustic coupling, ensuring reliable evaluation of material integrity without damage.
Akrometrix TherMoire PS200S Shadow Moire System
This precision metrology system measures thermal warpage and strain using the Shadow Moiré technique, which combines high-resolution imaging with fringe pattern analysis. It supports samples up to 150 mm square and can heat samples up to 300°C during measurement. Widely used in PCB, semiconductor packaging, and MEMS research, it delivers critical insights into thermal stress responses.
Dage XD7600NT X-Ray Inspection System
The DAGE XD7600NT delivers 2-megapixel resolution with 750 nm feature recognition using a reliable, filament-free X-ray tube. It provides comprehensive inspection with up to 70-degree oblique viewing and 360-degree live rotation. Automated measurement routines for BGA and die voids combined with detailed data logging make it indispensable for high-precision X-ray analysis.
Testing Machine Inc 80-91 Peel Tester
Designed for adhesion strength testing, this peel tester performs 90° and 180° peel tests with torque up to 25 lb-ft. It accommodates samples up to 6" × 12", providing reliable measurements for material bonding evaluation.
XYZtec Condor Sigma Bond Tester
The Condor Sigma offers versatile bond testing including wire pull, die shear, ball shear, and tweezer pull, with die shear forces up to 200 kg. It delivers precise, reproducible results for evaluating the strength and quality of microelectronic interconnects.
KLA Qualilab Elite V20 Chemical analyzer
This semi-automatic system monitors electroplating bath health via Cyclic Voltammetric Stripping (CVS) for organic additives and potentiometric titration for inorganic components. Capable of processing up to 10 samples simultaneously without operator intervention, it ensures consistent plating quality and process control.
KLA Qualilab Elite V10 Manual Chemical Analyzer
For manual electroplating bath analysis, the Elite V10 performs CVS to measure organic additives and titration to quantify inorganic components. This lab-based analyzer provides accurate, on-demand evaluation for maintaining plating bath performance.
Millibox MBX-03 Anechoic Chamber
Designed for over-the-air antenna testing up to sub-THz frequencies, this chamber offers a reflection-free environment with a precision 3D antenna positioner. Full rotational control enables comprehensive radiation pattern measurements critical for advanced antenna and electromagnetic compatibility (EMC) testing.
